Double Disc Grinder (Duplex)

lapping2

Double disc grinding machine Specially for Bearing races,having capacity min/max 8mm/50mm thickness & Diameter ranging from dia 10 mm to 80 mm.The unique feature of our m/c. is the both the wheel head slides on Rum type arrangement Instead of flat guideways to avoid coolant entry in to the guideways & there erodification of slideways the coolant thru spindle prove move effective in to the grinding zone A. Specification

Products


Models : DST - 350                                                                                                                    ;

1 Min./Max. thickness of job 3 mm t 50 mm
2 Min./Max. diameter of job 10mm to 80 mm
3 Grinding wheel head L. H. & R.H. 2 nos.
4 Grinding Wheel motor 2.2 KW (3 H.P.)(2 nos.)
5 Grinding Wheel size (OD X Thickness) Dia. 350 x 52mm
6 Coolant Through Spindle both the end.
7 Dressing Through Hydraulic Cylinder arrangement mounted on wheel head
8 Job feeding Through feed or Plunge feed depending upon the job rotating feeder can be supplied for plunge grinding of wasur
9 Grinding Wheel spindle Mounted on antification rollers & Thrust bearings
10 Total connecting load 6 KW
B Scope of supply

1 Micromakes - DST - 350 Double disc grinding machine with specification as per A & including
   following features.
2 Electric equipment for 3 Phase, 415 Volts, 50 Cycle AC supply.
3 Complete Coolant equipment with motor, pump and tank without magnetic clarifier unit.
4 Rotating disc feeder (Optional)
5 Suitable electric control cabinet.
6 Set of Belts.
7 Set of Service tools.
